The New Range of Electric Forklifts
High Voltage. High Performance. Hyundai.
The Next Generation B-X Series Electric Forklifts
With a 309-348V high-voltage system and advanced motor technology, the new 4 to 9 tonne Next Generation B-X electric counterbalance forklifts from Hyundai are leading the way in high performance with engine-like performance with fast travel and lift speeds. Designed and tested to work indoors and outdoors in extreme conditions and with less maintenance costs, these machines are ready to replace heavy-duty diesel models. With minimal noise and vibration plus fast charging, these forklifts will deliver a full day of productive working.
explore the range
40/45/50/55B-X
Load Capacity | 4000 - 5500 kg |
Drive Motor Rating | 309-348 V / 65 kW |
Lift Height | 2930 - 6540 mm |
Load Centre Distance | 500 - 600 mm |
60/70/80/90B-X/80B-XL
Load Capacity | 6000 - 9000 kg |
Drive Motor Rating | 348 V / 75 kW |
Lift Height | 3025 - 7650 mm |
Load Centre Distance | 600 - 900 mm |
Energy & Performance
Experience powerful performance and outstanding productivity of Hyundai's latest range of electric forklifts with the Next Generation high-voltage system. Engineered for demanding material handling applications inside and out, it delivers high power, sustainability, and efficiency — without compromise.
- Maximum Energy Efficiency – Less current is required to deliver the same power, reducing energy losses (I²R) and boosting overall system efficiency.
- More Power for Tough Jobs – High-voltage batteries deliver higher peak power, making them ideal for intensive material handling operations.
- Lower Heat Generation – FEH control system ensures faster, more accurate hydraulic response with up to 10% fuel savings.
- Faster Charging – Compatible with rapid charging technologies to minimise downtime and keep your operations moving.
- Ready for all Conditions – Engineered to perform reliably in outdoor environments, including rain, snow and extreme cold.
Convenience & Comfort
The Next Generation Hyundai B-X forklifts are designed to be quieter, smoother, and smarter — delivering greater operator comfort and improved productivity. Built for internal and external operations they combine advanced technology with exceptional handling.
- Low Noise, Low Vibration for Maximum Comfort – Electric powertrain and noise-reducing design, noise is reduced by up to 14 dB compared to diesel models
- Smart LCD Cluster Display for Real-Time Information – high-visibility LCD display shows battery status, machine temperature, error and warning alerts, driving mode selection, travel speed, load weight, and maintenance reminders
- Anti Roll-Back for Safer Slope Handling – Controls speed to prevent rollback, ensuring secure stopping and smooth restarts.
- Mast Damping Option for Improved Load Stability – Reduced vertical mast vibrations, increasing load stability and enhancing operator comfort
- Drive Mode Selection – Operators can choose the most suitable driving mode depending on their preferences and working environment.
Safety Without Compromise
Safety is non-negotiable. The Hyundai B-X Series integrates cutting-edge technologies to create a secure and reliable working environment for operators and pedestrians alike — making it ideal for internal locations such as warehouses, processing and manufacturing plants and external locations such as ports, airports, lumber yards and concrete works.
- Pedestrian Detection System (Optional) – smart onboard camera helps prevent collisions by detecting pedestrians near the forklift.
- Load Sensing System (Optional) – Displays the real-time weight of a lifted load on the operator cluster.
- Operator Presence Sensing System – Automatically disables driving and mast functions if the operator leaves the seat.
- Blue Spot & Red Zone Lighting (Optional) – Blue Spot projects a visible blue beam ahead or behind the forklift to warn pedestrians
- Charging Port Protection Cover – Shields the charging port from impact, dust, and moisture.
Maintenance Made Easy
Smart design choices in the Hyundai B-X Series ensure simple servicing, reduced maintenance costs, and long-term reliability. Keep your business moving with less downtime, lower operating expenses, and maximum uptime.
- Lower Total Cost of Ownership – save up to 70% annually on fuel and maintenance costs compared to diesel models
- High-Voltage System Cut-Off Switch – Manual Service Disconnect (MSD) plug provides complete isolation of the high-voltage system during servicing
- High-Voltage Cable Safety Design – Clearly marked cables with enhanced insulation and protective shielding provide safe handling
- Peace of Mind Warranty – Confidence in your investment with a comprehensive 3-5 year / 4,000 to 10,000 key hours warranty
- Data-Driven Fleet Management with Hi MATE – advanced Hi MATE system allows you to manage forklift fleets on-site with visualised data
